このエントリは、Shiny公式サイトのCustomize your UI with HTMLを抜粋・翻訳・追記したものです。
https://shiny.rstudio.com/articles/html-tags.html
Shinyアプリケーションに任意のHTMLを追加してカスタマイズする方法を説明します。
Shinyアプリケーションのユーザインタフェース(UI)はweb上のドキュメントであり、ui.RがHTMLを生成するRの関数を実行して、webアプリケーションに変換しています。
shinyUIが生成するHTMLの説明
例として、01_helloを取り上げます。以下の説明は、08_htmlと重複する部分があります。
library(shiny) runExample("01_hello")
上記のコードでサンプルアプリケーション「01_hello」が実行されます。01_helloのui.Rスクリプトを以下に示します。
library(shiny) # Define UI for application that draws a histogram shinyUI(fluidPage( # Application title titlePanel("Hello Shiny!"), # Sidebar with a slider input for the number of bins sidebarLayout( sidebarPanel( sliderInput("bins", "Number of bins:", min = 1, max = 50, value = 30) ), # Show a plot of the generated distribution mainPanel( plotOutput("distPlot") ) ) ))
このコードは以下の図のようなアプリケーションを生成します。
ui.Rスクリプト中shinyUI関数を呼び出します。shinyUI関数がHTMLを返すR関数を呼び出しています。コード内にHTMLを書く必要はなく、HTMLについて注意する必要はありません。以下のコードが返しているHTMLを、コメントアウトした行に記述します。
fluidPage( # Application title titlePanel("Hello Shiny!"), # Sidebar with a slider input for the number of bins sidebarLayout( sidebarPanel( sliderInput("bins", "Number of bins:", min = 1, max = 50, value = 30) ), # Show a plot of the generated distribution mainPanel( plotOutput("distPlot") ) ) ) ## <div class="container-fluid"> ## <h2 style="padding: 10px 0px;">Hello Shiny!</h2> ## <div class="row-fluid"> ## <div class="span4"> ## <form class="well"> ## <div> ## <label class="control-label" for="bins">Number of bins:</label> ## <input id="bins" type="slider" name="bins" value="30" class="jslider" data-## from="1" data-to="50" data-step="1" data-skin="plastic" data-round="FALSE## " data-locale="us" data-format="#,##0.#####" data-smooth="FALSE"/> ## </div> ## </form> ## </div> ## <div class="span8"> ## <div id="distPlot" class="shiny-plot-output" style="width: 100% ; height: ## 400px"></div> ## </div> ## </div> ## </div>
titlePanel("Hello Shiny!") ## <h2 style="padding: 10px 0px;">Hello Shiny!</h2>
上記のHTMLに、任意のHTMLを追加してカスタマイズするために、tags
オブジェクトを使用します。
tags
shiny::tags
は110個の関数のリストです。各関数でHTMLタグを追加してアプリケーションをビルドします。関数名と、追加するHTMLタグの名前は対応しています。それぞれのタグの詳細はShiny HTML tags glossaryに書かれています。
names(tags) ## [1] "a" "abbr" "address" "area" "article" ## [6] "aside" "audio" "b" "base" "bdi" ## [11] "bdo" "blockquote" "body" "br" "button" ## [16] "canvas" "caption" "cite" "code" "col" ## [21] "colgroup" "command" "data" "datalist" "dd" ## [26] "del" "details" "dfn" "div" "dl" ## [31] "dt" "em" "embed" "eventsource" "fieldset" ## [36] "figcaption" "figure" "footer" "form" "h1" ## [41] "h2" "h3" "h4" "h5" "h6" ## [46] "head" "header" "hgroup" "hr" "html" ## [51] "i" "iframe" "img" "input" "ins" ## [56] "kbd" "keygen" "label" "legend" "li" ## [61] "link" "mark" "map" "menu" "meta" ## [66] "meter" "nav" "noscript" "object" "ol" ## [71] "optgroup" "option" "output" "p" "param" ## [76] "pre" "progress" "q" "ruby" "rp" ## [81] "rt" "s" "samp" "script" "section" ## [86] "select" "small" "source" "span" "strong" ## [91] "style" "sub" "summary" "sup" "table" ## [96] "tbody" "td" "textarea" "tfoot" "th" ## [101] "thead" "time" "title" "tr" "track" ## [106] "u" "ul" "var" "video" "wbr"
divタグを生成するためには、以下のコードを実行します。
tags$div() ## <div></div>
主なタグには、tags$
なしのヘルプ関数が用意されています。例えばHTMLタグのcode
はtags$code
を呼び出します。tags$
を付けることなくヘルパー関数を呼び出せるタグ関数は、a, br, code, div, em, h1, h2, h3, h4, h5, h6, hr, img, p, pre, span, strong
です。
他のタグの名前を冠した関数はRのネイティブな関数と重複しているので、tags$
を付けて呼び出す必要があります。
属性(Attributes)
タグ関数の引数は、そのままHTMLの属性を与えられます。引数の名前が属性の名前、引数の値が属性の値です。例えば、divタグに属性を追加するときは、以下のように、
tags$div(class = "header") ## <div class="header"></div>
値無しで属性を追加するときには、NAを設定します:
tags$div(class = "header", checked = NA) ## <div class="header" checked></div>
タグ関数の引数にネストしたHTMLを追加
各タグ関数の中に、ネストしたHTMLを引数にして加えることができます。
tags$div(class = "header", checked = NA, tags$p("Ready to take the Shiny tutorial? If so"), tags$a(href = "shiny.rstudio.com/tutorial", "Click Here!") ) ## <div class="header" checked> ## <p>Ready to take the Shiny tutorial? If so</p> ## <a href="shiny.rstudio.com/tutorial">Click Here!</a> ## </div>
withTagsによるtags$の省略
withTags
関数内ではtags$
なしで、タグ関数を記述できます。
withTags({ div(class="header", checked=NA, p("Ready to take the Shiny tutorial? If so"), a(href="shiny.rstudio.com/tutorial", "Click Here!") ) }) ## <div class="header" checked> ## <p>Ready to take the Shiny tutorial? If so</p> ## <a href="shiny.rstudio.com/tutorial">Click Here!</a> ## </div>
01_helloのui.Rファイルに上記で説明したタグを追加すると、以下のコードになります。
library(shiny) # Define UI for application that draws a histogram shinyUI(fluidPage( # Application title titlePanel("Hello Shiny!"), # Sidebar with a slider input for the number of bins sidebarLayout( sidebarPanel( sliderInput("bins", "Number of bins:", min = 1, max = 50, value = 30), # adding the new div tag to the sidebar tags$div(class="header", checked=NA, tags$p("Ready to take the Shiny tutorial? If so"), tags$a(href="shiny.rstudio.com/tutorial", "Click Here!") ) ), # Show a plot of the generated distribution mainPanel( plotOutput("distPlot") ) ) ))
新しいHTMLとして、文とリンクが01_helloに追加されています。
属性と子HTMLタグへの条件式
タグ関数の引数にNULLを設定すると、その引数はHTML出力中に現れません。以下のようにif文で条件式を指定することもできます。
tags$div(class = "header", id = NULL, NULL, "line 2" ) ## <div class="header">line 2</div> tags$div(class = "header", id = if (FALSE) 100, if (FALSE) "line 1", "line 2" ) ## <div class="header">line 2</div>
List関数によるネスト
Rのlist
関数を用いて、タグに子のリストを渡せます。タグ関数内で呼び出したlist
は、そのタグの子としてリスト内の各要素が追加されます。
tags$div(class="header", checked=NA, list( tags$p("Ready to take the Shiny tutorial? If so"), tags$a(href="shiny.rstudio.com/tutorial", "Click Here!"), "Thank you" ) ) ## <div class="header" checked> ## <p>Ready to take the Shiny tutorial? If so</p> ## <a href="shiny.rstudio.com/tutorial">Click Here!</a> ## Thank you ## </div>
HTMLの直接出力
タグオブジェクト、またはShinyUI
の中に直接HTMLを記述することはできません。ShinyはHTMLそのままであれば、文字列として扱います。
tags$div( "<strong>Raw HTML!</strong>" ) ## <div><strong>Raw HTML!</strong></div>
HTMLをそのまま加えるためには、HTML
関数を用います。HTML
は(HTMLの)文字列を引数に取って、(Shinyの特別なクラスの)HTMLとして返します。
tags$div( HTML("<strong>Raw HTML!</strong>") ) ## <div><strong>Raw HTML!</strong></div>
HTML
に渡されたコードに不備があってもエラーを返さない、という点に注意する必要があります。
